How to operate automatic discharge gold knelson centrifuge concentrator?

As the technology development gold mining machinery,the automatic discharge gold knelson centrifuge concentrator are widly used.Below are operating details of automatic discharge gold knelson centrifuge concentrator.

Operation process

1)Open the PLC control box, turn on the main power, then getting into the system and setting parameters, waiting for the air compressor to inflate;

2)Start the centrifugal pump and adjust the water pressure to about 0.3MPa by switch. (the water pressure needs to sum up the experience and adjust itself according to the actual situation);

3)Click on the automatic mode of "Cycle" to start work;

4)Shut down: firstly should turn off the feeding of raw material, when discharge finished click "automatic stop", turn off the main power and finally turn off the centrifugal pump.

The maintainence

1)Because the knelson centrifuge gold concentrator is rotating at high speed, it will produce vibration, so we should check whether the bolt is loose or not at any time.If loose there will be abnormal sound, please stop in time to check.

2)Weather, temperature, humidity and other factors will have a greater impact on the life of V-belt, please check if need change please replace one whole set.

3)Butter must be added to each shift for 8 hours. Lack of oil can cause damage to bearings.

If problems cann’t be solved please contact Qingzhou Guancheng Heavy Industrial Machinery Co., Ltd. (It’s better to send photos,video to our company via email then we can response very soon)

Detail parameter
