Bucket&wheel type sand washing Plant & mineral process line

Technology process:

The raw material by excavator into the shaking feeder, separating out the useless materials, reducing the wear strength&improving work efficiency of trommel screen; and then through the feeding conveyor into the trommel screen to be separated into big size and small size,the big one transporting through the conveyor to the waste area;

The small one getting into the material tank through sluice and the first cleaning is carried out through the bucket type sand washing machine, and then the second time washing by sand washing machine,finally the clean sand transported by conveyor.

Detail parameter

 Production

 Specifications

 Quantity

 Power

 Remark

Shaking feeder

2200*3000mm

1pcs

5.5 KW


Trommel screen

Inner diameter1.3m,outside1.6m
Length3m

1set

11 KW


Bucket sand washing machine

Bucket70# height:3m,Arm width:1100mm,length:6800mm

1set

7.5 KW


Wheel sand washing machine

Wheel Ø2600*1800mm

1set

7.5 KW


 Feeding conveyor

Belt width:600mm,pole length 7m

1set

5.5 KW


 Tailing conveyor

Belt width:600mm,pole length 6m

1set

5.5 KW


Clean sand conveyor

Belt width:600mm,pole length 6m

1set

5.5 KW


Water pump


1pcs

7.5 KW


Electricity cabint


1pcs

-


 Total power

55.5KW
Generate units of120KW are suggest to use.
